StormBeam 1500X RGBW IP65 LED Pixel Moving Strobe Light

The StormBeam 1500X RGBW IP65 LED Pixel Moving Strobe Light, is an IP65-rated outdoor moving strobe light that fuses raw power, precision control, and unmatched versatility. Designed for demanding stage environments, massive festivals, and high-energy productions, this hybrid fixture combines two powerful light sources—784 x 1.5W RGB SMD LEDs and 392 x 2W Cold-White LEDs—to deliver a visual experience like no other.

Unrivaled Visual Impact

At the core of the StormBeam 1500X is its dual-light system. The bright white dual strobe tube creates sharp, intense bursts, while the surrounding full-color RGB array adds depth, color, and movement. Use them independently or combine them for explosive effects that captivate any audience.

Precision Pixel Control

With 14 RGB zones and 28 white zones, you gain full control over every inch of light output. Create intricate pixel-mapped designs, animated effects, or dramatic washes—all programmable via DMX/RDM and compatible with most lighting consoles.

Dynamic Tilt Movement

The fixture offers smooth 8–16 bit resolution and a 200° tilt range for sweeping motion and accurate light placement. Whether positioned as an overhead blinder, a wall wash, or a floor-mounted strobe, the StormBeam adapts seamlessly.

Rugged, Road-Ready Design

Built with IP65 protection, die-cast aluminum housing, and temperature-controlled cooling, the StormBeam thrives in harsh environments—from outdoor concerts to indoor clubs. With PowerCom IP65 connectors and universal power input, it’s made for professional tours and rental setups.

Key Features:

  • Strobe/Wash/Blinder multi-functional light fixture
  • 784 RGB + 392 Cold-White LEDs
  • 14 RGB Zones + 28 CW Zones for pixel mapping
  • 200° motorized tilt with 8–16 bit control
  • Support DMX, RDM control
  • 7 DMX Channel mode with 8/11/13/24/30/74/ 97CH
  • Selectable PWM frequency up to 25kHz for flicker-free filming
  • 0–20Hz strobe, dimming curves, and color macros
  • IP65-rated for outdoor/wet conditions

SPECIFICATIONS

Model No.

StormBeam 1500X

Input Voltage

100-240VAC, 50/60Hz

Power Max.

1500W

Light Source

784 x 1.5W RGB 3in1 SMD LEDs (14 Zones)

392 x 2W White LEDs (28 Zones)

Movement

Resolution: 8-16Bit

Tilt (Degrees): 200°

Control and Programming

Control Protocol

DMX512, RDM

DMX Channels

8CH/11CH/13CH/24CH/30CH/74CH/97CH

RDM

Bidirectional communication

Dynamic Effects

14 x RGB LED zones with individual control

28 x CW LED zones with individual control

0-100% continuous dimming

0~20Hz sec and pulse effect

4 kinds of dimming mode

Outstanding color mixing

Built-in programming, color changing macro

Selectable PWM : 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

Construction

Housing Material

die-casting aluminum

Housing Color

Black

Display

LCD display

Data Connectors

3-pin and 5-pin IP65 XLR,

Power In/Out

PowerCon IP65 In/Out

Protection Rating

IP65, temporary outdoor/wet use

Work  Temperature (Ambient):

14 °F to 113 °F (-10 °C to 45 °C)

Cooling

Temperature controlled, overheating protection

Dimensions

502 x 148 x 337mm

Weight

N.W:12.0 kg,  G.W:15.0kg

Shipping

Cardboard box,

8-way or 4-way flight case options available

 Let's see this amazing lighting effects of StormBeam 1500X RGBW IP65 LED Pixel Moving Strobe Light on YouTube link as below

 https://youtu.be/uFgSgEpTF2c
