PIXEL STRIP 100 RGBW | 100W Hybrid Pixel LED Wash Bar
RGBW Wash. White Illumination. Dynamic Pixel Effects.
PIXEL STRIP 100 RGBW is a compact indoor hybrid LED batten designed for stage lighting, event production, clubs, theatres, DJ setups and creative entertainment environments.
Its three-part LED system combines 12 × 3W RGBW LEDs for rich color wash, 156 × 0.5W 5730 White LEDs for smooth white illumination, and 96 × 0.25W RGB LEDs for dynamic pixel effects.
With a 6° beam angle, individual pixel control, DMX512/RDM support and up to 122 DMX channels, PIXEL STRIP 100 RGBW delivers flexible wash and creative pixel animation in a lightweight 2.86kg fixture.
Key Features
- ✓ Hybrid LED System: RGBW Wash + White Illumination + RGB Pixel Effects
- ✓ 12 × 3W RGBW + 156 × 0.5W White + 96 × 0.25W RGB LEDs
- ✓ Individual Pixel Control with up to 122 DMX Channels
- ✓ DMX512 / RDM / Master-Slave / Auto / Sound Active
- ✓ Lightweight 2.86kg design with 6° narrow beam
Product Overview Video
Technical Specification
OPTICAL & LIGHT SOURCE
- RGBW Source: 12 × 3W RGBW LEDs
- White Source: 156 × 0.5W 5730 White LEDs
- Pixel Source: 96 × 0.25W RGB LEDs
- Beam Angle: 6°
- Radiation Angle: 8°
- Strobe Frequency: 1–30Hz
EFFECTS & PIXEL CONTROL
- Pixel Control: Individual pixel control
- Effects: Running, chasing, flashing and gradient effects
- Dimming: 0–100% linear dimming
CONTROL
- Control Modes: DMX512, RDM, Master/Slave, Auto, Sound Active
- DMX Channels: CH8 / CH20 / CH122
ELECTRICAL
- Input Voltage: AC100–240V, 50/60Hz
- Rated Power: 100W
PHYSICAL & CONSTRUCTION
- Protection: IP20 Indoor Use
- Working Temperature: -30°C to 50°C
- Net Weight: 2.86kg
- Gross Weight: 3.24kg
CONNECTION
- DMX: DMX512 In/Out
- Power: Power In/Out for daisy chaining
Optical Performance & Pixel Structure
Optical Data
- Beam Angle: 6°
- Radiation Angle: 8°
- RGBW LEDs: 12 × 3W
- White LEDs: 156 × 0.5W 5730
- RGB Pixel LEDs: 96 × 0.25W
Need custom DMX profiles, CAD or photometric files for your lighting console and visualizer?
Visit Download CenterDimensions & Physical Structure
Compact and lightweight linear design for easy transportation, installation and multi-fixture deployment.
Inner Package Size: 106 × 100 × 130 mm | Net Weight: 2.86 kg
Detailed product dimensions and 2D/3D CAD drawings are available from our technical team.
Stage & Event Applications
A flexible indoor pixel wash solution for professional and creative lighting environments.
PIXEL STRIP 100 RGBW vs Traditional LED Battens
A compact hybrid approach for lighting designers and rental companies that need both wash performance and creative pixel effects from one indoor fixture.
Why Rental Companies Choose PIXEL STRIP 100 RGBW
A practical fixture for building affordable multi-unit pixel lighting systems.
Wash + White + Pixel
Combines RGBW color wash, dedicated white LEDs and RGB pixel effects in one compact fixture.
Only 2.86kg
Easy to transport, install and deploy in multi-fixture event and rental applications.
Up to 122CH
Advanced pixel control plus DMX512, RDM, Auto, Master/Slave and Sound Active modes.
Technical Resources
Access official documentation, software files, and engineering drawings via our central portal.
Download Center
Access full library of Datasheets, GDTF, IES, CAD, and User Manuals.
Visit Download CenterNeed CAD / Console Profile?
Directly connect with our technical engineers for customized fixture support.
Contact EngineerBuild Your Pixel Lighting System
Combine PIXEL STRIP 100 RGBW with YUE YUAN pixel and outdoor lighting solutions for complete event systems.
Recommended Pixel Lighting Packages
Practical multi-unit configurations for indoor rental, event and entertainment applications.
Indoor Pixel Wash Starter Package
A compact pixel lighting package designed to create coordinated wash, white and dynamic pixel effects across stage backdrops and event spaces.
- ✓ 8 × PIXEL STRIP 100 RGBW — Hybrid Pixel LED Wash Bar
- ✓ DMX512 Control — Individual pixel and effect programming
- ✓ Daisy-Chain Power & DMX — Efficient multi-fixture deployment
Frequently Asked Questions
Is PIXEL STRIP 100 RGBW suitable for outdoor use?
No. PIXEL STRIP 100 RGBW is an IP20 indoor fixture. For outdoor applications, consider the IP65-rated PIXEL STRIP DUO 200IP.
How many DMX channels does PIXEL STRIP 100 RGBW support?
It provides 8CH, 20CH and 122CH DMX modes, with the 122CH mode providing advanced individual pixel control.
What makes this fixture different from a standard LED batten?
It combines RGBW wash LEDs, dedicated white LEDs and RGB pixel LEDs, allowing one fixture to provide wash, white-light and dynamic pixel effects.
