3-in-1 Visual Functionality
One compact fixture combines beam, wash and eye-candy effects for flexible production use.
VIDEO
Hybrid MAC ONE 150W RGBL LED Moving Head Light
A compact hybrid moving head delivering beam, wash and eye-candy effects in a single, tour-ready fixture.
Powered by a 150W RGBL LED engine and a mesmerizing Fresnel lens, Hybrid MAC ONE combines sharp beam performance, smooth wash coverage and vibrant eye-candy effects in a single, tour-ready design. Its motorized zoom, high-output optical system and compact footprint make it ideal for live events, rental inventories and permanent installations.
- 150W RGBL LED engine with smooth color mixing
- Beam, wash and eye-candy effects in a single fixture
- Motorized zoom range from 4° to 27°
- 24 × 0.25W RGB LEDs for backlight effects
- Compact, lightweight, rental-friendly design
Hybrid MAC ONE — Quick Answer
Quick Answer
HYBRID MAC ONE is a compact 4.5kg RGBL hybrid moving head with a 150W RGBL LED engine, 4°–27° motorized zoom and 24 × 0.25W RGB backlight LEDs, combining beam, wash and eye-candy effects.
Key Decision Factors
RGBL LED Engine
The 150W RGBL engine provides RGBL color mixing in a compact moving-head platform.
4°–27° Motorized Zoom
The zoom range provides flexibility from concentrated beam looks to wider wash coverage.
24 × 0.25W RGB Backlight
The dedicated RGB LEDs create additional backlight and face-effect visual layers.
Compact 4.5kg Design
The lightweight chassis reduces transport and handling burden for touring and rental operations.
Network Control
DMX, Art-Net and sACN support integration into professional lighting-control workflows.
SPECIFICATIONS
OPTICAL
- Light Source: 1 × 150W RGBL LED engine
- Backlight: 24 × 0.25W RGB LEDs
- Lens: 150mm Fresnel
- Peak Intensity (Narrow): 375,000 cd
- Total Output: up to 5,700 lm
- Zoom: Motorized 4°–27°
- Color Mixing: RGBL
- CTO: 2000K–12,850K (±200K)
- LED Lifetime: >50,000 hours
MOVEMENT
- Pan: 540°
- Tilt: 240°
- Resolution: 16-bit
CONTROL
- Protocols: DMX, Art-Net, sACN
- DMX Modes: 20CH-1 / 36CH / 108CH / 20CH-2
- Display: LCD menu
ELECTRICAL
- AC 100–240V, 50/60Hz
- Power Consumption: 180W
PHYSICAL
- Housing: Flame-retardant thermoplastic
- Cooling: Intelligent fan cooling
- Power: powerCON TRUE1 TOP
- DMX: 5-pin XLR In/Out
- Ethernet: etherCON In/Thru
- Dimensions: 255 × 185 × 370 mm
- Net Weight: 4.5 kg
- Mounting: Omega bracket
- IP Rating: IP20
APPLICATIONS
- Touring productions
- Rental staging
- Concerts & live shows
- Clubs & venues
- Corporate events
